DB6 | DIN 2714 | AISI L6
(1)(1)_edited.png)
Key Features
-
High Toughness and Ductility
-
Excellent Thorough Hardnening Response
-
Superior Thermal Fatigue Resistance
-
Good machinability in Annealed condition
Size Range
Round Bar
80 mm To 500 mm Diameter
Flat Bar
80mm*80mm To 500mm*350mm
About the Steel
DB6 Die Block Steel is a high-performance Die steel known for its excellent toughness, deep hardenability, and resistance to thermal fatigue. Engineered for heavy-duty die applications, DB6 maintains structural integrity under high impact and cyclic thermal loads. It offers good machinability in the annealed state and responds well to heat treatment, ensuring uniform hardness across large sections. Its balanced alloy composition makes it ideal for large forging dies, die casting tools, and extrusion dies where durability and dimensional stability are critical.
Applications
-
Closed Die Forging Dies
Withstands repeated high-impact forging loads.
-
Die Casting Molds
Ideal for aluminum and zinc pressure die-casting dies.
-
Hot Work Tooling
Used in tools exposed to elevated temperatures and thermal cycling.
-
Punches and Mandrels
Excellent for parts requiring wear and shock resistance.
Manufacturing
Process flow for manufacturing DB6 steel
Melting
Ingots melted in EIF, impurities fully killed followed by mandatory LRF and VD process
Forging
Hammer or press forged with reduction ratio of 3.5 to 4.5 times
Heat Treatment
Post forging annealing followed by Hardneing, Quenching and Double Tempering
Quality Test
Ultrasonic, Hardness, Mechanical, Microstructure testing of the metal at a NABL approved lab
Proof Machining
Proof machining of Forged Rounds and Flats as per Client's requirements
